Product code: 1445
Signal System:
1080/60i,
30p, 24p
1080/50i,
25p
720/60p,
30p, 24p
720/50p, 25p
720pN Variable Frame Rates:
60 Hz mode:
12, 18, 20, 22, 24, 26, 30, 32, 36, 48, 60 fps
50 Hz mode:
12, 18, 20, 23, 25, 27, 30, 32, 37, 48, 50 fps
NTSC:
480/60i, 30p, 24p
PAL:
576/50i, 25p
Image Device: 2/3"
3CCD
Horizontal Resolution: 1080 Lines
Sensitivity: F10 at 2000 lux
Built-in Filters ND:
Clear, 1/4, 1/16, 1/64
LCD Monitor: 3.5"
Viewfinder: 1.5" CRT B/W, NTSC/PAL Switchable
Memory Card Slot: SD Memory Cards for Scene-File Sharing
4 P2 Card Slots for Video
Shutter Speed Range: 1/12 to 1/2000 sec (Range depends on
Record Mode)
Gain Selection: 0-18 dB Range
Audio Signal Format: 16 bit/48kHz Four Channels
Audio Frequency Response: 20Hz to 20kHz
Input and Output Connectors:
Composite:
BNC (x1 Output)
Component:
D4 Terminal (x1 Output)
SDI/HD-SDI:
BNC (x1 Output)
Timecode:
BNC (x1 Input, x1 Output)
FireWire:
6-Pin
DC Power:
XLR (x1 Input, x1 Output)
Remote:
10-Pin
Lens: 12-Pin
EVF: 20-Pin
USB 2.0:
4-Pin (Type-B)
Microphone:
XLRx2 (x1 Input)
Analog
Audio: XLRx2 (x1 Input)
Line Out:
Pin Jack
Headphone:
3.5mm Stereo Mini Jack
Power Requirements: 12 VDC (11-17V)
Power Consumption: 23W
Operating Temperature: 32-104°F (0-40°C)
Dimensions (WxHxD): 5.6 x 10.4 x 12.6" (14 x 26.1 x
31.8 cm)
Weight: 8.4 lb (3.8 kg)
